πŸ’» Revit API Setup for Beginners (This will save you a lot of time!)

Jul 25, 2025

Setup Dev Environment

It's time to dive into actionable code.

However, before we begin, let's make sure that you all setup your Dev Environment correctly to follow along the upcoming newsletters.

So let's install it step by step together. Ready?

Prefer Video?

In case you'd rather follow along the video, then Click Here to watch the video tutorial on YouTube.


Install Essential Revit API Add-ins

When working with Revit API, we need a few Add-ins:

  • pyRevit (duh…)

  • Revit Lookup

  • RevitPythonShell (optional, but useful)

All of them are Free to use and open-source.


Install Revit Lookup (MUST HAVE)

Firstly, let's install Revit Lookup, which is by far the most used add-in for any Revit API developer.

πŸ’‘ This Add-in allows you to look behind the scenes and explore your Revit elements.

You will see attributes and all available data in Revit API for selected elements. This is great because you can see names of Properties that you have to use and also see the values that will be returned.


Install Revit Python Shell

The second plugin we can install is optional and it's RevitPythonShell.

This plugin was developed by Darren Thomas and it's also the base on which pyRevit was built. This provides you a python shell inside of Revit, which can be useful for testing and debugging small code snippets.

But keep in mind that it might not be maintained for Revit 2025+ anymore. It works well in Revit 2023, but I'm not even sure if it works for Revit 2024. So it's up to you if you want to install it or not.

Here is how it looks in Revit.


Download Revit API Stubs

Next, we're going to install and setup our IDEs (Code-Editors).

But first, we need to download Revit API stubs from here.

You will also find a video on how to create Revit API stubs yourself, but you can just download it from under the video.

Once you download, place it somewhere safe on your PC, for example:

  • C:\Users\USERNAME\AppData\Roaming\revitapi_stubs

πŸ’‘ You can call the folder anything you want.


Configure IDE (Code-Editor)

Lastly, we need to download and configure your IDE (code-editor) to enable Revit API Autocomplete, which is necessary step for any Revit API developer.

Firstly you can download both IDEs:

Secondly, you need to configure them for Revit API.

I would recommend you to 🎦 Watch Video Lesson for Step by Step Instructions.

If you prefer written format, have a look at the lesson summary, where I've included code snippets, GIFs and everything you might need.


What is Venv?

Virtual Environments(venv) allows us to preconfigure python environment for different purposes with its own set of packages, references and stubs.

We will have to create 1 or multiple virtual environments in pyCharm, so we can provide Revit API stubs to multiple versions and then switch between them with a click.

Check the video to learn more about it.


What about AI?

This is a game-changer.

I wish I had AI when I started to look over my shoulder and help me with simple stuff.

Which one?

To be honest, it doesn't matter which one you choose, it matters that you have it. There are free options, but paid will give you more juiceπŸ§ƒ.

Popular options:

  • GitHub CoPilot

  • TabNine

  • Codeium

  • Cody

  • Continue AI (for local LLMs with ollama)

  • CodeWhisperer (Amazon)

​

You can also get an AI-Powered IDE like:

  • Cursor IDE

  • TRAE IDE

​

I won't go in details how to install it, there are plenty of videos and it's easy to do on your own.

In general you install extension, create an account and it works out of the box.

If not sure, grab GitHub CoPilot it's the default option for many.


P.S.

And once you setup your Dev Environment you'll be ready for the next newsletter lessons where we'll dive deeper into the code starting with Selection basics.

Enjoyed Newsletter?

Leave a Testimonial Here.

⌨️ Happy Coding!
Erik Frits
